Access

AP-ESG-3010P, 8Ports 1000Mbps PoE with 2*1G SFP Uplink + 1Console Port

  • 8Ports 1000Mbps PoE with 2*1G SFP Uplink + 1Console Port
  • Rack Mount
  • 125W Power Budget
  • 96Gbps Switching Capacity

AP-ESG3024P, 24Ports 1000Mbps PoE with 4*1G Combo Uplink Ports

  • 24Ports 1000Mbps PoE with 4*1G Combo Uplink Ports +1Console Port
  • Can transfer data for network surveillance cameras.
  • 24x 1000Mbps auto-sensing POE ports, 4x 10/100/1000M Combo ports, 1 Console.
  • Support IEEE802.3/IEEE802.3i/IEEE802.3uIEEE802.3ab/IEEE802.3z, IEEE802.3af/at.
  • Compatible with IEEE802.3at (30W) and IEEE802.3af (15.4w).
  • Ethernet port supports 10/100/1000M adaptive and POE functions.
  • Panel indicator monitoring the status and help failure analysis.
  • Fanless design, natural cooling, 1U rack mount.
  • Support 802.1x port authentication, support AAA authentication, support TACACS+ authentication.
  • Support WEB, TELNET, CLI, SSH, SNMP, RMON management.
  • Support POE power management.
  • Support port lightning protection Surge: General Mode 6KV, Differential Mode 4KV, ESD 15KV.

AP-ESG3048P, 52 Port 10G Uplink 48 Ports Gigabit L2+ Management Ethernet PoE switch

  • Support IEEE 802.1d, IEEE 802.1w, IEEE 802.1s, IEEE 802.1p, IEEE 802.3. IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ae standard.
  • L3 management,support DHCP Server, QoS, ACL Control, SNMP V1/V2/V3, IGMP Snooping v1/v2.
  • Support STP/RSTP/MSTP (ERPS), Support loop detection and self-healing, remote loop back monitoring and control (802.3ah OAM).
  • Support multiple VLAN divisions, MAC VLAN, protocol VLAN, and Private VLAN.
  • Support IP address +MAC address +VLAN+ port binding, DHCP Snooping, IP source and DAI protection.
  • Support IPV4/ IPV6, RIP, OSPF.
  • Surge Protection: Common mode6KV, Differential 2KV; ESD:Contact 6KV. Air 8KV.
  • Support WEB, TELNET, CLI, SSH, SNMP, RMON management.
  • Support PoE watchdog, PoE Port power supply, Power configuration and PoE time management

AP-SG4500-12GT-P-4XFP, L2 10G Intelligent Access Switch

  • 8Ports 1000Mbps PoE with4*10G Uplink Ports + 1Console Port
  • 1 Console, 1 USB port
  • PoE+, up to 125w
  • AC power supply
  • Switching capacity: 96Gbps
  • Forwarding rate: 71.4Mpps

AP-SG4500-24GT-P-4SFP, 24Ports 1000Mbps PoE with 4*1G Uplink Ports

  • 24Ports 1000Mbps PoE with 4*1G Uplink Ports
  • Can transfer data for network surveillance cameras.
  • 24x 1000Mbps auto-sensing POE ports, 4x 10/100/1000M Combo ports, 1 Console.
  • Support IEEE802.3/IEEE802.3i/IEEE802.3uIEEE802.3ab/IEEE802.3z, IEEE802.3af/at.
  • Compatible with IEEE802.3at (30W) and IEEE802.3af (15.4w).
  • Ethernet port supports 10/100/1000M adaptive and POE functions.
  • Panel indicator monitoring the status and help failure analysis.
  • Fanless design, natural cooling, 1U rack mount.
  • Support 802.1x port authentication, support AAA authentication, support TACACS+ authentication.
  • Support WEB, TELNET, CLI, SSH, SNMP, RMON management.
  • Support POE power management.
  • Support port lightning protection Surge: General Mode 6KV, Differential Mode 4KV, ESD 15KV.

AP-SG4500-24GT-P-4XFP, 24Ports 1000Mbps PoE with 4*10G Uplink Ports

  • 24Ports 1000Mbps PoE with 4*10G Uplink Ports +1 Console Port
  • Can transfer data for network surveillance cameras.
  • 24x 1000Mbps auto-sensing POE ports, 4x 10/100/1000M Combo ports, 1 Console.
  • Support IEEE802.3/IEEE802.3i/IEEE802.3uIEEE802.3ab/IEEE802.3z, IEEE802.3af/at.
  • Compatible with IEEE802.3at (30W) and IEEE802.3af (15.4w).
  • Ethernet port supports 10/100/1000M adaptive and POE functions.
  • Panel indicator monitoring the status and help failure analysis.
  • Fanless design, natural cooling, 1U rack mount.
  • Support 802.1x port authentication, support AAA authentication, support TACACS+ authentication.
  • Support WEB, TELNET, CLI, SSH, SNMP, RMON management.
  • Support POE power management.
  • Support port lightning protection Surge: General Mode 6KV, Differential Mode 4KV, ESD 15KV.

AP-SG4500-10GT-2SFP, 8Ports 1000Mbps with 2*1G SFP Uplink + 1 Console Port

  • 8Ports 1000Mbps with 2*1G SFP Uplink + 1 Console Port
  • Rack Mount
  • Switching Capacity 20Gbps
  • Packet Forwarding 14.9Mbps
  • Mac Adress 8K

AP-SG4500-12GT-4XFP, 8Ports 1000Mbps with 4*10G Uplink Ports + 1 Console Port

  • 8 x 10/100/1000Base-T + 4 x 10GE(SFP+)
  • 1 Console, 1 USB port
  • AC power supply
  • Switching capacity: 96Gbps
  • Forwarding rate: 71.4Mpps

AP-SG4500-28GT-4SFP, 24Ports 1000Mbps with 4*1G Uplink Ports + 1 Console Port

  • 24Ports 1000Mbps with 4*1G Uplink Ports + 1 Console Port
  • Rack Mount
  • 56Gbps Switching Capacity
  • 41.6Mbps Packet Forwarding
  • 8K Mac Address

AP-SG4500-28GT-4XFP, 24Ports 1000Mbps PoE with 4*10G Uplink Ports + 1 Console Port

  • 24Ports 1000Mbps with 4*1G Uplink Ports + 1 Console Port
  • Rack Mount
  • 128Gbps Switching Capacity
  • 95Mbps Packet Forwarding
  • 16K Mac Address

AP-SG4500-52GT-4SFP, 48Ports 1000Mbps with 4*1G Uplink Ports + 1 Console Port

  • 48Ports 1000Mbps with 4*1G Uplink Ports + 1 Console Port
  • Rack Mount
  • 104Gbps Switching Capacity
  • 95Mbps Packet Forwarding
  • 16K Mac Address

AP-SG4500-52GT-4XFP, 48Ports 1000Mbps with 4*10G Uplink Ports + 1 Console Port

  • 48Ports 1000Mbps with 4*10G Uplink Ports + 1 Console Port
  • Rack Mount
  • 176Gbps Switching Capacity
  • 131Mbps Packet Forwarding
  • 16K Mac Address

AP-SG5550-24XE, 24Ports 1000Mbps Copper Ports with 4*10G Uplink Ports+1 Console Port

  • 24Ports 1000Mbps Copper Ports with 4*10G Uplink Ports+1 Console Port
  • Rack Mount
  • Power Supply: Dual Power AC/DC
  • Switching Capacity: 128Gbps
  • Packet Forwarding: 95Mbps
  • MAC Address: 16K
  • Layer 3 Routing: Static Routing, OSPF v3,BGP4+
